UR33 is a special model of rapier loom, which is suitable for weaving Velveteen, velvet, plush, industrial fabrics, etc., including sofa flannel, automobile decorative flannel, curtain flannel, clothing flannel, home textile flannel, light carpet, worship blanket, etc.
|
Reed width |
190cm , 230cm , 260cm , 280cm , 320cm , 340 cm , |
|
Loom speed |
Up to 500 rpm / min, economical speed 250-350 rpm / min (depending on the configuration given width) |
|
Pile height |
0-10mm |
|
Applicable weaving material |
Cotton, hemp, wool, chemical fiber, real silk, man-made fiber, etc., long fiber 20-1000D , man-made fiber 5-500Tex , cotton: 3 s -80 s |
|
Main drive |
Servo motor |
|
Warp beam |
Φ 800mm ground warp, Φ 800mm or Φ 1000mm velvet warp |
|
Selvage |
1. Selvedge device: independent electronic selvedge 2. Electronic side jacquard device (optional) 3. Hot-melt edge (optional) |
|
Cloth roll method |
Double cloth winding device outside the machine, single cloth winding maximum Φ 800mm |
|
Parking device |
1. Electronic menstrual stop 2. Weft stop: electronic high-sensitivity piezoelectric detection device 3. Parking display: the control panel displays the reason for parking, multi-function four-color light display
|
|
Velvet structure |
W type, V type, U type |
|
Scope of application |
Velveteen, velvet, plush, industrial fabrics, etc., including sofa flannel, automobile decorative flannel, curtain flannel, clothing flannel, home textile flannel, light carpet, worship blanket, etc. |
